RoHS 94v0 Multilayer Printed Circuit Board Multifunctional Practical

Brand Name : OEM

Model Number : HKCC2211YH109

Certification : ISO/RoHS/TS16949

Place of Origin : China

MOQ : 5pcs

Price : USD10-USD100

Payment Terms : T/T

Supply Ability : 600000 Piece/Pieces per Year circuit board

Delivery Time : 20 workdays

Packaging Details : Vacuum Package inside, Carton outside

Silk Screen : White, Black, etc.

Layer : 1,2,4,6...52Layer

Twist&Wrap : ≤ 0.5%

Layer to layer Rrgistration : +/-0.003"

Min Plated Drills to Copper : 0.25mm, 0.30mm

Copper Thickness : 1~4oz

Contact Now

Product Description

94v0 Rohs Car Navigation Multilayer Printed Circuit Boards Assembly

Files and Requirment for PCB,PCBA quotation:

A BOM (Bill of Materials) with reference designators: component description, manufacturer’s name and part number.
PCB Gerber files.
A PCB fabrication drawing and PCBA assembly drawing.
Test procedures.
Any mechanical restrictions such as assembly height requirements

PCB board manufacture and PCBA service:
- o PCB board made, circuit board parts purchased by us
- o Electronic testing circuit board or PCBA
- o Fast delivery, anti-static package
- o RoHS Directive-compliant, lead-free
- o One stop service from PCB design, PCB layout, PCB manufacture, components purchasing, PCB assembly, test, packing and PCB delivery
- o Eleectronic manufacturing service
Detailed terms for PCB assembly:
- o Technical requirement:
  - § Professional surface-mounting and through-hole soldering technology
  - § Various sizes like 1206, 0805, 0603 components SMT technology
  - § ICT (In Circuit Test), FCT (Functional Circuit Test) technology
  - § PCB assembly with UL, CE, FCC, RoHS approval
  - § Nitrogen gas reflow soldering technology for SMT
  - § High standard SMT and solder assembly line
  - § High density interconnected board placement technology capacity
- o Quote requirement:
  - § Gerber file and Bom list
  - § Clear pics of pcba or pcba sample for us
  - § Test method for PCBA
- o PCB specification:
  - § Layer: 1 to 12 layers
  - § Material: FR-4, CEM-1, CEM-3, Hight TG, FR4 halogen free, FR-1, FR-2,Aluminum etc.
  - § Max. finished thickness: 0.2 to 4.0mm (0.02 ~ 0.25″)
  - § Max. finished board side: 500 x 500mm (20 x 20”)
  - § Min. drilled hole size: 0.25mm (10mil)
  - § Min. line width: 0.10mm (4mil)
  - § Min. line spacing: 0.10mm (4mil)
  - § Surface finish/treatment: HALS/HALS lead free, chemical tin, chemical gold, immersion gold, plating gold
  - § Copper thickness: 0.5 to 3.0 oz
  - § Solder mask color: green/black/white/red/blue
  - § Inner packing: plastic bag
  - § Outer packing: standard carton packing
  - § Hole tolerance: PTH: ±0.076, NTPH: ±0.05
  - § Certificate: UL, ISO 9001, ISO 14001, RoHS,UL
  - § Profiling punching: routing, V-cut, beveling
  - § Providing OEM service to all sorts of printed circuit board assembly

Silk Screen	White, Black, etc.
Layer	1,2,4,6...52Layer
Twist&Wrap	≤ 0.5%
Packaging Details	Vacuum Package inside, Carton outside
Supply Ability	600000 Piece/Pieces per Year circuit board
Layer to layer Rrgistration	+/-0.003"
Min Plated Drills to Copper	0.25mm, 0.30mm
Copper Thickness	1~4oz
Board Thickness	0.5~3.2mm
Max. Panel Size	541*647mm(Special can do to 950mm)
